Terrapin
CC1-T Active Drop-Tile Speakers | Sonos Built-in
CC1-T Active Drop-Tile Speakers | Sonos Built-in
SKU:CC1-T-POE-1x2-WH-PAIR
LEAD TIME: Ships in about 14 Days
Sold As PAIR
Couldn't load pickup availability
Share
The Terrapin CC1-P Drop-Tile speaker is a 1x2' custom drop-in speaker that is compatible with the ultra-popular SONOS® wireless audio system. Our CC1 series of active speakers are plug n play ready to work natively with your Sonos wireless audio system. And can be powered via standard AC electrical hard-wiring, or optionally over network via popular PoE+. Both allow for wired or wireless connectivity for data.
The CC1 Drop-Tile with Sonos built-in provides a great BGM audio option for small businesses, where ease of install and use is key. You get all the native streaming and control that Sonos offers, but with a stealthy design that blends in perfectly.
Tile replacement speakers work great with all 2' or wider drop-ceilings grids, and are popular with offices and small shops. They will work equally well in a home too though, if your homes design calls for this type of speaker style. A steel backcan provides Plenum compliance, passive cooling, and an included 24" T-Bar for adapting any grid. It's ready for use in most any indoor environment.
The super efficient Sonos module and robust power supply drive a 3" woofer and 1" tweeter, offering clear highs and mids. While the heavy shell design provides great cabinet resilience, and combined with the ported design, provides smooth bass response down to 65 hz. With a coaxial design the speaker has a wide dispersion angle of 100 degrees for wide coverage. Easily pair with other Sonos speakers to create a zone, and even add a Sub for increased fidelity.
Available for purchase with either 100-240v power option, or powered by network PoE+. Comes in White or Off-White option. Wired and Wireless network for data is standard on both version.
Optionally we offer premium Gripple brand 10' adjustable wire hangers, so you can quickly and easily secure your speaker tile to structure.
Compatibility
Compatibility
Sonos Compatibility
You can add CC1 Tile speaker as you would any other Sonos speaker from settings in your Sonos S2 App (not designed for use with S1 App). The app will find 'Symfonisk' speaker, then simply rename to match your location. All other standard Sonos app functions work accordingly.
Pro Zones (2025 Q1 Sonos App Update) - This product is not currently compatible with the new Pro Zones function in the Sonos app.
Disclosure - Terrapin is a company providing aftermarket parts or modified systems for use with the SONOS. We are not affiliated with Sonos or IKEA. Symfonisk is a brand name of IKEA/SONOS. This device is solely warranted for fitness and workmanship by Terrapin, but any tech support for the Sonos setup, app or functions should be directed to Sonos support.
Features & Specs
Features & Specs
SOLD AS A PAIR (Specs are per speaker unit)
- Dimension: 12-1/4" W x 5" H x 23 7/8" D (1x2 model)
- Dimension: 23-7/8" W x 5" H x 23 7/8" D (2x2 model)
- Weight: 6 lbs (1x2 model) / 8 lbs (2x2 model)
- Woofer: 3" PP
- Tweeter: 1" Dome
- Power Output: 50watt (Max)
- Color: White grille (Black back)
- AC Power Version: 100-240v
- PoE Power Version: PoE+ 802.3AT (25w) (RJ-45)
- Accessories: 1x T-Bar 24"
- Material: Various Plastics and Steel
- Sound Dispersion: 100 Degrees
- WiFi: SonosNet and 2.4 & 5 Ghz Wifi
- Wired Network: Yes ( RJ45 ) (PoE+)
- All steel backcan - Meets Minimum Plenum Req.
- Safety Wire Attachment Point (wire not included)
Documents
Documents
SPEAKER GUIDE (PDF)
